Slide 112 of 119
Notes:
A catch basin is an inlet to the storm drain system that typically includes a grate or curb inlet where stormwater enters the catch basin and a sump to capture sediment, debris and associated pollutants. They are also used in CSO watersheds to capture floatables and settle some solids. Catch basins act as pretreatment for other treatment practices by capturing large sediments. The performance of catch basins at removing sediment and other pollutants depends on the design of the catch basin (e.g., the size of the sump), and maintenance procedures to retain the storage available in the sump to capture sediment.
